abstract
Aqueous biphasic systems (ABS) have been largely investigated for the extraction, separation and/or purification of biomolecules. Recently, the use of ionic liquids (ILs) as additives in conventional polymer-based ABS was proposed to overcome the limited range of polarities of the coexisting phases. However, the impact of ILs on the partitioning of biomolecules on IL additivated ABS is not universal and is still poorly understood. Aiming at obtaining additional insights on this matter, the effects of the chemical structure of the lL, tie-line length (TLL) and biomolecule nature upon the partition of a series of model biomolecules were investigated. For this purpose, ternary ABS (composed of polyethylene glycol (PEG) 400, citrate buffer at pH 7.0, and water), and several quaternary ABS (composed of PEG 400, citrate buffer at pH 7.0, water and ILs at 5 wt%), were prepared using different chloride-based ILs ([C(4)mimjCI, [C(4)mpyrlCl, [C(4)mpip]Cl, [P-4444]Cl and [N-4444]Cl). The partition of a wide range of biomolecules in these systems (gallic acid, vanillic acid, eugenol, nicotine, caffeine, L-tryptophan, L-phenylalanine and I. tyrosine), used here as molecular probes, was studied. These solutes were chosen due to their wide range of polarities. The results obtained support the concept that ILs, when used as adjuvants in polymer-based ABS, change the coexisting phases' characteristics and modify the partition behavior of biomolecules. In general, a positive effect derived from the use of ILs as adjuvants in PEG-salt systems is observed, particularly when dealing with more hydrophobic biomolecules, whereas IL + salt ABS perform better in the extraction of more hydrophilic biomolecules. The favourable partition of more hydrophilic biomolecules in IL + salt ABS seems to be ruled by specific interactions with the IL, while the favourable partition of more hydrophobic biomolecules in PEG + salt and PEG + salt + IL seems to be governed by the differences in the phases hydrophobicities. It is shown that ILs preferentially migrate to the PEG-rich phase, and that there is a correlation between the partition coefficients of the biomolecules and ILs and the biomolecules octanol-water partition coefficients. (C) 2017 Elsevier B.V. All rights reserved.
keywords
2-PHASE SYSTEMS; POLYETHYLENE-GLYCOL; EXTRACTION; PURIFICATION; SEPARATION; PROTEINS; BEHAVIOR
subject category
Engineering
authors
Sousa, RDS; Pereira, MM; Freire, MG; Coutinho, JAP
our authors
Mara Guadalupe Freire Martins
Coordinating Researcher
Matheus M. Pereira
Researcher
Rita de Cássia Superbi de Sousa
Post-doc FellowshipGroups
G4 - Renewable Materials and Circular Economy
G5 - Biomimetic, Biological and Living Materials
G6 - Virtual Materials and Artificial Intelligence
acknowledgements
This work was developed in the scope of the project CICECO-Aveiro Institute of Materials (Ref. FCT UID /CTM /50011/2013), financed by national funds through the FCT/MEC and co-financed by FEDER under the PT2020 Partnership Agreement. M. M. Pereira acknowledges the PhD grant (2740-13-3) and financial support from Coordenacao de Aperfeicoamento de Pessoal de Nivel Superior - Capes. Rita de Cassia S. Sousa acknowledges the Post-doctoral grant (200833/2015-4/PDE) and financial support from Conselho Nacional de Desenvolvimento Cientifico e Tecnologico - CNPq. M. G. Freire acknowledges the European Research Council (ERC) for the Starting Grant ECR-2013-StG-337753.
